Miniature Circuit Board Size



EAR Micro Platform

~1 sq. cm., plus wings for sensors, battery connections, etc.

Industry Standard

~2 to 3 sq. cm for the main circuit, plus wings for sensors, battery connections, etc.

T10 Bespoke / T20 by EAR Micro

Main circuit area on T10 Bespoke is 12.7 mm x 8.9 mm (1.13 sq. CM) for all primary electronics. A separate wing folds around the battery to support two mics, IMU, and multi-gesture cap-sense touch surface combined with patent-pending Micro LDS antenna





Min. Electronics Volume, Including Battery



EAR Micro Platform

.628 cu. Cm (smallest in the world, utilized for Piearcings product:  www.piearcings.com)

Industry Standard

2 to 4 cubic centimeters. Airpod pros are appx 2.5 cu. Cm, Surface buds are approx 6 Cu. Cm! (huge)

T10 Bespoke / T20 by EAR Micro

1.38 cu. Cm (nearly 1/2 the size of Airpod Pro--which is closest rival form-factor)





Small Enough to Fit Into Other Wearables

Multiple Form-Factor Utility Patents Granted to EAR Micro

(Watches, Straps, Bracelets, Earrings, etc.)



EAR Micro Platform

Yes

Industry Standard

No, plus would violate EAR Micro's IP

T10 Bespoke / T20 by EAR Micro

Yes, T10 Bespoke slips into world’s slimmest charger, which doubles as key fob, necklace pendant, or pocket-watch style device





Power Consumption

While Streaming Music

Industry Standard

8-15 mA

EAR Micro Platform

5.5 mA

T10 Bespoke / T20 by EAR Micro

5.5. mA





Proprietary Battery

World-Wide Exclusive to EAR Micro for Hearables

EAR Micro Platform

47-56 mAh per cell, available in optional chemistries optimized for either maximum capacity, or incredibly fast charging (4-5C, or full capacity in under 30 min). Battery is a laser-welded stainless case that cannot expand, cannot leak. Ultimately compact, ultimately safe

Industry Standard

Standard Varta coin-cell, or Chinese. (Larger, and less energy density). Cells tend to be inconsistently manufactured, can be volatile *(dangerous), are designed to expand and ‘vent’ noxious chemicals in the event of battery degradation/failure

T10 Bespoke / T20 by EAR Micro

Single EAR Micro cell in the T10 Bespoke (available in either selected chemistry) Double EAR Micro cell in the T20. Allows up to 9 hours playback time in the T10, 16 hours in the T20. In fast-charge version, battery can be charged to 85% capacity in 15 min





Bluetooth Audio Streaming

EAR Micro Platform

24bit/up to 96kHz using Sony LDAC codec

Industry Standard

16bit/44.1kHz, some at 24/48 using APTx or APTxHD

T10 Bespoke / T20 by EAR Micro

24bit/up to 96kHz using Sony LDAC codec





ANC

Feed Forward, Feed Back, and Hybrid ANC

EAR Micro Platform

Yes

Industry Standard

Yes

T10 Bespoke / T20 by EAR Micro

T10 Bespoke are Feed Forward.  T-20's are Hybrid





Max On-Board (Stored) Audio Playback Resolution

EAR Micro Platform

24bit/192kHz

Industry Standard

Few support, but some at 24/48

T10 Bespoke / T20 by EAR Micro

OTA and side-loaded media storage/playback not utilized on T10 Bespoke however WILL be used on upcoming T20 (high-def audio in-ear monitiors) @ 24/192





Built-In Program-Accessible RAM on SIP/SOC

EAR Micro Platform

2 MB to 64MB

Industry Standard

0 MB

T10 Bespoke / T20 by EAR Micro

64MB





Compatible With Additional External Memory

EAR Micro Platform

Yes

Industry Standard

No

T10 Bespoke/ T20 by EAR Micro

No on T10 Bespoke, Yes on upcoming T20 product, (utilizes micro SD--so user can determine amt. of memory to add)





Processor

EAR Micro Platform

ARM M4, integrated into SIP

Industry Standard

*QC 51xx, very difficult to customize and program.  No operating system integration, No a.i. integration

T10 Bespoke/ T20 by EAR Micro

ARM M4, integrated into SIP





DSP’s



EAR Micro Platform

Twin Tensilica HiFi, open architecture, easily customized, integrated into SIP

Industry Standard

*Qualcomm Kalimba, severely outdated, only a handful of individuals in the world familiar with and capable of programming)

T10 Bespoke / T20 by EAR Micro

Twin Tensilica HiFi , open architecture, easily customized, integrated into SIP





Microphones

(Per Ear Computer)

EAR Micro Platform

Up to 6, including in-canal, can be standard mems analog or digital, (nearly-unlimited) custom keyword/key-phrase detection handled entirely through OS on the m4 ARM

Industry Standard

2-4, generally external only, must use Knowles IA 610/611 smart-mic for (very limited) keyword detection, only "Alexa/Google/Siri" today

T10 Bespoke / T20 by EAR Micro

T10 Bespoke uses 4 standard mems analog, custom keyword/key-phrase detection handled entirely through OS on the m4 ARM. T-20 uses 6 mics:  4 mems analog for beam-formoing, plus 2 Mems in-canal hybrid ANC + windless voice)





Sensor Integration

EAR Micro and Bragi Hold Key IP

EAR Micro Platform

Virtually unlimited, utilizes I2C bus, plus Bragi OS

Industry Standard

Not natively supported for customization by QQ, difficult/time-consuming to integrate

T10 Bespoke / T20 by EAR Micro

6 axis IMU used in conjunction with mics for positional awareness (left or right ear) plus novel mouth gestures, plus head gestures





Multi-Gesuture Micro-Mechanical Deflection-Based Cap-Sense Touch

Patent Granted to EAR Micro



EAR Micro Platform

Up to 8 pads, fully customizable gestures, including pressure sensitivity

Industry Standard

QC 51xx, cap sense no longer supported on chip, must use separate chip and custom software to support multi-gesture, no pressure sensitivity

T10 Bespoke / T20 by EAR Micro

Supports touch, double touch, touch and hold, swipe forward, swipe rearward, swipe and hold forward, swipe and hold rearward, toggle forward, toggle rearward, toggle and hold (both directions), all gestures (for each ear) independently assignable in-app





Non-Verbal Mouth-Based Interface

Patent Granted to EAR Micro

EAR Micro Platform

Controls hearable without voice, and without hands (click teeth, tongue snitch, etc.)

Industry Standard

Not available, would infringe EAR Micro IP

T10 Bespoke / T20 by EAR Micro

Included: control hearable without voice, and without hands (click teeth, tongue snitch, etc.). Used in conjunction with Bragi 4D head-gestures to create virtual ‘point and click’ menu structure for the hearable, protected by EAR Micro and Bragi IP





Head Gesture Interface

Patent by Bragi, Licensed to EAR Micro



EAR Micro Platform

Extended gestures through Bragi OS, including 4D virtual menu integration (virtual mouse), plus Mouth gesture (patented by EAR Micro) for click/selection of list items

Industry Standard

Not available, would infringe Bragi IP and EAR Micro IP

T10 Bespoke / T20 by EAR Micro

Extended gestures through Bragi OS, initial T10 Bespoke includes head nod, head shake, and (later) software upgrade for 4D virtual menu integration (virtual mouse), plus mouth gesture (patented by EAR Micro) for click/selection of list items





MIDI Interface

Patent Pending to EAR Micro



EAR Micro Platform

Use of hearable as a musical instrument device interface

Industry Standard

Not available, would infringe EAR Micro IP

T10 Bespoke/ T20 by EAR Micro

Yes, in future software updates





Operating System

Multiple Patents Licensed From Bragi, Who Holds Key IP



EAR Micro Platform

Bragi O.S. customized in partnership with EAR Micro. Enables seamless participation in the burgeoning new space for 3rd party “hearables apps”

Industry Standard

Qualcomm (firmware only), no ability to download hearables apps to upgrade or enhance the product

T10 Bespoke / T20 by EAR Micro

Bragi O.S. customized in partnership with EAR Micro, several pending T10 Bespoke hearables apps to debut alongside product





SDK Available



EAR Micro Platform

Yes (coming soon), allows outside app developers to write hearables apps and/or integrate hearables support to existing apps

Industry Standard

No

T10 Bespoke / T20 by EAR Micro

Yes (coming soon), allows outside app developers to write hearables apps and/or integrate hearables support to existing apps





A.I.

Patents by EAR Micro and Bragi



EAR Micro Platform

EAR Micro and Bragi Nano AI., combined to support on-board situational awareness, on-board gesture processing, and other fully customizable features

Industry Standard

No

T10 Bespoke / T20 by EAR Micro

Supports on-board situational awareness, on-board gesture processing, and other fully customizable future features (workout detection, detection of reps for pushups/situps/other floor exercises, auto-transparency audio pass through during calls or when user is speaking, etc.





Chassis Design

Patent Pending by EAR Micro



EAR Micro Platform

EVERGREEN and FUTURE-PROOF:  Allows replacement of battery, repairs, upgrades to circuit board, ability to swap-out mechanical components, remove/replace/upgrade speaker cartridge, etc.

Industry Standard

No, all other hearables are mechanically fixed, cannot be opened or repaired easily. Not upgradable as tech evolves. Planned 2-3 year EOL means more landfill bait the moment the batteries are shot and won’t hold a charge

T10 Bespoke / T20 by EAR Micro

Yes, fully utilizes exclusive EAR Micro Chassis Design. T10 Bespoke hearables chassis will be a viable platform for decades to come; just like the company’s famous Klipsch Horns; in continuous production for nearly 70 years
